Feature:
●IP68 proof, can adapt to harsh working environment
●Excellent decoding ability and ultra-high sensitivity
●Good at scanning DPM carved barcodes, worn barcodes, highly reflective bar codes, high-density barcodes, miniature barcodes and other difficult barcodes
●Using adaptive frequency hopping technology, stable data transmission and strong anti-interference ability, Even in the harsh industrial environment, it can still be transmitted stably
●Good ergonomic design, for long-time working
Application
●Manufacturing, such as electronics, machinery and automobile manufacturing
With the megapixel high-resolution engine and a variety of well-designed lenses and lighting systems, scanner can not only read any standard 1D and 2D barcodes, but also read various difficult barcodes frequently encountered in manufacturing industry.
●Warehousing and logistics
It can scan efficiently both in poorly lit warehouses and outdoors in direct sunlight.
●Cold chain and wharf
Competent in cold of -20°C and soaked in Water
●Other occasions where bar codes are complex or use environment
DPM verison:
White DPM Advantages:
1. tiny barcodes;
2. Highly reflective barcode;
3. Curved barcode
Advantages of DP:
1. Dot matrix barcode
2. More considerable scanning depth of field
Specification:
| Color | Black |
| Power | DC 5V±0.25V , Current:HP:220mA(Max) 90mA(Standby) |
| Lighting & Aiming | HD&HP:White & Red Lighting, Red LED Aiming DP:Automatic multi-color LED Lighting, Red Laser Aiming |
|
Resolution | Million pixels |
| Scanning Angle | ±72°,±72°,360°(Skew,Pitch,Roll) |
| Code Resolution | HP:1D≥3mil 2D≥6mil DP:1D≥3mil 2D≥4mil |
Contrast | ≥20% |
| Symbologies. | 2D:QR Code,Micro QR,Data Matrix,PDF417,Micro PDF417, Aztec,Maxicode |
| Scan Ability | Printed,Spraying,DPM,screen code |
| Alert Mode | Buzzer (volume and tone adjustable), LED light, vibrator |
| Cable Length | Standard: 2 meters USB cable |
| Interface | USB-HID,USB-COM,P/S2,RS232 ,RS485,ethernet,Profinet |
| Usage | Handheld manual,Consecutive Scanning, Auto-sensing |
| Material | Bi-color:ABS+PC/TPU Single:ABS Transparent:PC Waterproof ring:Silica gel |
| Temperature | -20°C-55°C(operation), -40°C-70°C(storage) |
| Humidity | 5%-95% (non-condensing) |
| Drop | Unit functions normally after repeated -6.5ft.(2m)drops to concrete |
| Luminance | 0~100,000LUX |
| Setting Way | Scan the setting barcode |
| Scan window | Scratch-resistant toughened glass |
| Sealing | Scanner:IP68 |
| Barcode Setting | Support Prefix,Suffix,Insert,truncate&replace string.Change code length or other setting |
